The CRAFTSMAN® Z5200 zero-turn riding mower provides an optimum mowing experience. Its strong 20 HP Kohler® 7,000 twin-cylinder engine provides the power and reliability you need to get the job done. Equipped with a 42-inch steel deck, robust steel frame design, and dual range hydrostatic transmission for durability and control. This mower will provide an exceptional ride as you power through the lawn in comfort and support thanks to a high-back seat. You can add an optional mulching kit to create the perfect finishing touches by returning nutrients to your soil for a healthier lawn. Give your yard a professional look with the CRAFTSMAN® Z5200 zero-turn riding mower.

• Powerful engine: Powered by a reliable 20 HP Kohler® 7000 twin-cylinder engine

• Adjustable lap bar: Easy to operate 3-way adjustable lap bar

• Comfort: Rubber foot pad allows you to focus on the task at hand by providing a smoother ride and help reduce vibration

• Increased traction control: 20x8/11x6 Turf Master® tires offer excellent traction without damaging your yard

• Durable: 42-in stamped steel deck holds up against tough obstacles

• Cut-and-sew seat: High-back seat provides comfort and support to make sure the job gets done right

• Warranty: 3-year limited product manufacturer warranty and 5-year frame warranty

General
Series Name	Z5200	Type	Zero-turn riding lawn mower
Sub-Type	Lawn tractor



Dimensions
Assembled Weight (lbs.)	600	Fuel Capacity (Gallons)	3.5
Cut Width (Inches)	42	Overall Length (Inches)	84
Cutting Range/Yard Size (Acres)	1-2 acres	Overall Width with Deck (Inches)	48
Engine Oil Capacity (oz.)	64	Rear Wheel Size	20-in
Front Wheel Size	11-in



Features
Ammeter
Bagger Capable	Yes	Maximum Forward Speed (MPH)	7
Blade Engagement Type (PTO)	Electric	Maximum Reverse Speed (MPH)	3.5
Cruise Control	No	Mulching Capable	Yes (kit sold separately)
Deck Gauge	13	Number of Blades	2
Deck Type	Stamped	Number of Deck Positions	8
Discharge Location	Side	Number of Deck/Anti-Scalp Wheels	2
Drive Type	Rear wheel drive	Oil Filter Type	Spin-on
Engine Brand	KOHLER
